AS-41DPA (4 ports Display Port KVM switch, Single-monitor)

•

contact

● 4 port USB2.0 multiple video series KVM switch
● Single USB controls 4 sets of computers and peripherals USB
● Built-in USB2.0 hub, compatible with USB2.0 protocol specification
● DP video maximum support resolution is 4K@60fp
● Provide keyboard hot-key switching shortcut function and device panel button two switching function selection
● Support multiple platforms for various operating systems
● BIOS level hardware connection, no need to install drivers and control software
● The front panel of the device is extended with a USB interface, which is convenient for users to connect peripheral devices such as a USB keyboard, a mouse, or a USB flash drive or a USB printer .
● Provide a variety of hot-key selection and setting functions, so that users can set their own hot-keys according to the situation.
● Automatically scans the connected computer

Type			AS-41DPA
Computer connections			4
Port selection			Front panel buttons/Hotkey
Connector	Control port	monitor	1 x DP Type A black Female
		keyboard	1 x USB Type A female
		mouse	1 x USB Type A female
		speaker	1 x Mini stereo jack female (green)
		microphone	1 x Mini stereo jack female (pink)
	Computer port	monitor	4 x DP Type A female (black)
		Keyboard & mouse	2 x USB Type B female (white)
		Speaker & microphone	4 x Mini stereo jack female (black)
	Power		1 x DC socket
Toggle switch	KVM switch button		4x button
LED’s	Online		4 x red
	Selected		4 x green
Analog mode	Keyboard & mouse		USB
Maximum resolution video			4K @ 60HZ( 3840x2160 @60HZ)
Hotkey			CTL+CTL
Operating environment	Operating temperature		0-50 °C
	Storage temperature		-20-60 °C
	Humidity		0-80% RH , no condensation
Housing	House		metal
	Size		20211044mm
	Weight		0.50Kg
