AS-21DPA (2 ports Display Port KVM switch, Single-monitor)


● 2 port USB2.0 multiple video series KVM switch
● Single USB controls 2 sets of computers and peripherals USB
● Built-in USB2.0 hub, compatible with USB2.0 protocol specification
● DP video maximum support resolution is 4K@60fp
● Provide keyboard hot-key switching shortcut function and device panel button two switching function selection
● Support multiple platforms for various operating systems
● BIOS level hardware connection, no need to install drivers and control software
● The front panel of the device is extended with a USB interface, which is convenient for users to connect peripheral devices such as a USB keyboard, a mouse, or a USB flash drive or a USB printer .
● Provide a variety of hot-key selection and setting functions, so that users can set their own hot-keys according to the situation.
● Automatically scans the connected computer

Type

AS-21DPA

Computer connections

2

Port selection

Front panel buttons/Hotkey











Connector

Control port

monitor

1 x DP Type A black Female

keyboard

1 x USB Type A female

mouse

1 x USB Type A female

speaker

1 x Mini stereo jack female (green)

microphone

1 x Mini stereo jack female (pink)

Computer  port

monitor

2 x DP Type A female (black)

Keyboard & mouse

2 x USB Type B female (white)

Speaker &

microphone

2 x Mini stereo jack female (black)

Power

1 x DC socket

Toggle switch

KVM switch button



2 x button



LED’s

Online

2 x red

Selected

2 x green

Analog mode

Keyboard & mouse

USB



Maximum resolution video

4K @ 60HZ( 3840x2160 @60HZ)

Hotkey

CTL+CTL

Operating environment

Operating temperature

0-50 °C



Storage temperature

-20-60 °C

Humidity

0-80% RH , no condensation

Housing

House

metal

Size

132 x 92 x 44mm

Weight

0.50Kg
