KVM MATRIX Series with 17inch Monitor

•

contact

1-local user, 4 Remote users Access 16 Ports Cat5 KVM over IP

Hardware
● Supports One local user and 4 remote users;
● High-density connection port - RJ-45 connection port up to 16 ports on Cat 5e/6 connection
● Built-in 1000 Mbps network adapter cards with IP function
● Support USB and serial (RS-232),485, VGA/DVI/HDMI connections
● Local console supports USB or PS.2 keyboard and mouse
● Support cross-platform server environment: Windows, Mac, Sun, Linux, etc. based serial devices
● High video resolution - local console video and remote video resolution up to 1920x1200@60Hz
● Up to 16 servers can be monitored at a single level, or up to 256 servers can be managed through cascade function
● The connection port of controlled computer keyboard and mouse are with keep online technology to simulate keyboard and mouse function; switch fast, device safe and stable.

Management
● Provide up to 3000 groups of user accounts, users can be divided into 3 levels according to their permissions
● Support terminating online functions – administrators can terminate online working
● Support log generation and conditional query function of KVM device system
● Support firmware update
● Support information setting and storage function of connecting device ports and customization of device connection information
● Port sharing mode allows multiple users to access a server at the same time
● User rights and group management, users can be divided into super administrator, administrator and user
● Support permission settings, administrators can set operation rights and ports for different level users
● Embedded WEB management server makes management way fast and reliable.

17” LCD Console Specification:

Type		17” LCD Console-AS7100TLS(F)
LCD Monitor	Ratio	17” Screen, 4:3
	Video	SXGATFT-LCD
	Visible Square	337.920(H) × 270.336(V)
	Resolution	12801024@60HZ(Opitmum)/19201200@60HZ(Max)
	Support Color	16.7M (RGB 6 bit + Hi_FRC)
	Contrast	1000 : 1 (Typ)
	Backlight	LED
	Pixel Pitch	0.264x0.297mm
	LEDMTBF	100,000 hours
	Input power	12V
Keyboard (demountable design)	Keyboard	100Keys, detachable (9 different languages for choose)
	Compatible IBM/AT	Microsoft Windows9, Me/NT/2000/XP, WIN7, Server2003, WIN8, WIN10
	Port	Standard PS/2; USB
	Using life	>1,000,000 Times
Mouse	Type	Touch Screen
	Port	Standard PS/2
	X/Y Resolution	>1000dots/inch, (40x40/mm)
	Using life	>1,000,000 Times
Installation Dimension	40744545mm
Weight	6.15kg

Module Specification:

Function			AS7416TLS
Computer Connection	Direct Connects		16
	Maximum Connects		256
Port Selection			OSD Menu、Remote IP
Connectors	Console Connector	Monitor	1 x VGA DB15 Blue Female
		Keyboard	1 x USB Type A Female、1 x PS2 purple Female
		Mouse	1 x USB Type A Female、1 x PS2 Green Female
	PC Connector	Switch Module	16 x RJ45 port
	Power		2 x DC Jack
	IP Network Port		1 x RJ45 (2 / 4 Remote users)
	485control port		1 x RJ45
Switch	KVM Reset		1 x Semi-embedded button
	KVM factory reset		1 x Semi-embedded button
	Remote control		2、4 x green LED
Analog Mode	Keyboard Mouse		USB、PS2
Maximum resolution			1920 x 1200 @ 60HZ local & remote
Scanning interval			3、5、10、15、20、30、40、60seconds（Default 3 seconds）
Operating environment	Operating temperature		0-50℃
	Storage temperature		-20-60℃
	Humidity		0-80%RH，No Condensation
Physical Properties	Housing		Metal
	Size		440 x 350 x 44 mm
	Weight		4.2KG
