LIS-0316AM Specification


● Remote users can monitor PDU and loop status on web pages
● Support safe shutdown function
● Each device has its own power supply and socket.  The user interface can be accessed even when the overload state triggers the automatic power-off switch on this device
● Fire surge is protection, reduce the risk of fire caused by surge.
● Remote power management via TCP/IP and built-in 10/100 Ethernet port
● Support network communication protocols: TCP/IP, UDP, HTTP, DHCP, 10BASE-T /100Base-TX,  Ping
● Individual power sockets can be controlled locally and remotely (open, close, cycle switch)
● Power on sequence - The user can set the power on sequence and the delay time for each socket so that the device can be turned on in the appropriate sequence
● It can be easily set and operated through the browser interface
● Support for multiple browsers (IE, Mozilla, Firefox, Chrome, Safari, Opera, Netscape)
● It can measure the power status of the PDU loop of the whole power distributor
● Current and voltage critical setting
● Provides the socket naming function
● Support activity log
● Supports firmware upgrade
● Support multiple languages: English, simplified Chinese
● Configurable mail notification feature to keep your system notified of changes in status
● Flexible mounting design for easy mounting on structured wiring enclosures, walls or behind tables and televisions.
● Supports SNMP management
● RTC supports timer operation in the absence of power supply
● Support multi-user Settings, and multi-user different management rights Settings
● Support PDU energy usage statistics, quickly understand the usage of electrical equipment through graphics
● PDU Exterior The PDU provides LED indicators to visually display the operating status of ports and hosts
● Dynamic password verification in the log-in window enhances user log-in security verification
● You can add and query scheduled tasks to make work plans for PDU port sockets in advance
● Displays current and voltage alarms on the home page, and queries historical records of PDU anomalies
● Support zero meter clearing function

Function

              LIS-0316AM

Power Outlets

Direct

3

Connectors

Power Inlet

1 x IEC C14

Power Outlets

American standard three hole socket

LAN

1 x RJ-45 (F)

LEDs

Outlet Status

3(Green)

Power

1 (Green)

LAN

10/100M

1 (Orange / Green)

Link

1 (Green)

Switches

Reset

1 x Semi-recessed button

Restore default Settings

1 x Semi-recessed button

Power

1 x Rocker Switch

I/P Rating

100–240V~; 50/60Hz; 16A

Load Capacity

3840W

O/P Rating

Per Port

100–120V~; 50/60Hz; 10A



Total

100–120V~; 50/60Hz; 16A

Environment

Operating Temperature

0–50oC

Storage Temperature

-2060oC

Humidity

080% RH Non-condensing

Physical

Properties

Housing

Metal

Weight

0.85Kg

Dimensions (L x W x H)

198*133*44.5cm
